Justice

A plaster acoustic panel with circular perforations 45mm at 85mm centres, forming a continuous pattern when joined.

New York Collection is perfect for interior designers and architects who are looking for aesthetic designs coupled with high acoustical properties.

New York Collection is the subtle, innovative solution for creating a unique decorative finish while providing a high level of sound absorption for ceilings and walls.

New York Collection ceiling and wall panels are available in three unique designs with either round perforations, square perforations or a very stylish slotted design.

Features

1. Full acoustic perforations
2. Simple installation screw fix to steel or timber battens
3. Flush jointing
4. Precise lines
5. Three unique and innovative designs

Benefits

• High sound absorption with NRC up to 0.85
• Reduces noise reverberation
• Unique and innovative designs which can only be achieved with cast plaster
• Prevents dust entering into room space
• Reduces echo
• Able to help to distinguish between music and speech

Panel Name: Justice

Collection: New York

Thickness (mm): 13

Thickness of Insulation (mm): 2 or 50

Size(mm): 1200 x 1200

NRC: 0.55¹ 0.75²

Mass (Kg/sqm): 10.76

¹ Black Acoustic Fabric
² 50mm 32Kg/m2 Glasswool/Polyester

All tiles and panels are supplied without insulation or acoustic backing as standard.

Acoustic tests shown here are examples of what can be achieved for NRC using different insulation methods.

Mechanically fixed (screwed to Rondo Furring Channel Part No 155)
